Product Introduction
☆ Hot-pluggable QSFP28 form factor, compliant with the QSFP28 MSA
☆ 4 channels full-duplex
transceiver modules
☆ Up to 28Gb/s per channel,
112Gb/s aggregate bit rate
☆ Support InfiniBand EDR
☆ Single 3.3V power supply
☆ 4x25Gb/s VCSEL/DFB/EML
transmitter
☆ 4x25G electrical interface
☆ Built in full digital
diagnostics functions
☆ I2C management interface
☆ Maximum link length of 40km
on SMF/100m on MMF
☆ Power dissipation <5W
☆ Temperature range 0°C to
70°C
☆ RoHS-6 Compliant
|
P/N |
Package |
Distance |
Wavelength |
Source |
Fiber |
Output Power |
Sensitivity |
|
N-QS-100GL01 |
QSFP28 |
100m |
850nm |
VCSEL |
MM |
-8.4～2.4dBm |
≦-10.3dBm |
|
N-QS-100GLC2 |
QSFP28 |
2km |
CWDM |
DFB |
SM |
-6.5～2.5dBm |
≦-11.5dBm |
|
N-QS-100GL2 |
QSFP28 |
2km |
1310nm |
DFB |
SM |
-5.5～2.0dBm |
≦-10.2dBm |
|
N-QS-100GL10 |
QSFP28 |
10km |
4 LAN WDM |
DFB |
SM |
-4.3～+4.5dBm |
≦-10.6dBm |
|
N-QS-100GL40 |
QSFP28 |
40km |
4 LAN WDM |
EML+APD |
SM |
-2.9～+3.3dBm |
≦-16.9dBm |
